1. Introduction

As the leading cause of death globally, cardiovascular disease (CVD) encompasses a range of disorders affecting the heart and blood vessels, including coronary heart disease, valvular heart disease, and congenital heart disease, claiming over 20 million lives annually.1 Over the past three decades, CVD-related deaths have increased by 60% and continue to rise.2 In the United States, more than half of the adult population experiences some form of CVD, ranging from early onset to late-stage disease.3 The heart’s minimal regenerative capacity makes it highly susceptible to irreversible damage, often leading to heart failure.4 Alarmingly, projections estimate that over 8 million people in the United States will suffer from heart failure by 2030.5 By 2050, the annual healthcare costs associated with CVD—currently $393 billion—are expected to rise to $1.49 trillion.6

As the CVD prevalence continues to rise, researchers have increasingly relied on advanced in vitro cardiac models as essential tools for developmental and disease modeling, drug testing, and regenerative medicine. Diverse cardiac tissue models—such as two-dimensional (2D) cultures, engineered three-dimensional (3D) constructs, and animal models—have been developed, but none fully replicate the structural and functional complexity of native heart tissues.7 The structural and biological complexity of the human heart presents significant challenges in engineering functional cardiac tissue.8 Technologies such as 3D bioprinting, an additive manufacturing process that deposits cells, biomaterials, and bioactive molecules in a spatially controlled manner, have been used to fabricate diverse cardiac constructs, ranging from simplified 2D myocardial sheets to complex 3D miniature hearts.9,10 Many bioprinting modalities have been explored in cardiac applications, each offering unique advantages depending on the intended application. However, regardless of modality, bioprinted cardiac constructs often fail to fully replicate native cardiac function due to limitations in cellular organization, vascularization, and functional maturation.7,9,10

Organoids are self-organizing 3D tissues derived from stem cells that recapitulate aspects of native tissue architecture and function. Cardiac organoids, sometimes referred to as cardioids, represent promising advancements in cardiac in vitro modeling.11 Through guided stem cell differentiation, cardioids, unlike pre-patterned tissue constructs, exhibit self-organizing properties, allowing them to form physiologically relevant cardiac structures, including chamber-like morphologies without predefined scaffolds.12 This developmentally driven self-organization makes cardioids valuable for studying cardiogenesis and congenital diseases. However, despite their advantages, cardioids remain limited in their applicability to adult cardiac applications due to microscale size, immaturity, poor vascularization, and lack of reproducibility.12–14

Merging bioprinting with cardioid technology could overcome the challenges of generating scalable, vascularized, and functionally mature cardiac tissues. By using bioprinting as a tool to guide cardiac structures into forming adult-like structures through self-organization, physiologically relevant and mature, engineered cardiac tissue can be generated in a scalable and highly reproducible manner. This review will first examine key aspects of the cardiac bioprinting workflow, including its use in fabricating myocardial constructs, heart valves, vascular grafts, etc. Next, we will provide a detailed discussion of cardioids, including their defining features, current applications, and limitations. Finally, we will assess recent progress toward bioprinting cardioids, outline the challenges involved, and propose potential solutions integrating bioprinting and cardioid technology.

2. Cardiac bioprinting

The bioprinting process consists of three key stages: pre-processing, processing, and post-processing (Figure 1). This section will explore critical considerations for each of these stages that are essential for obtaining prints with structural integrity and functional maturation, focusing on bioink properties, cell selection, bioprinting techniques, and methods for construct maturation.


Figure 1. Process map of cardiac tissue bioprinting. The bioprinting workflow consists of three primary stages: pre-processing, processing, and postprocessing. Pre-processing includes CAD selection/generation, cell selection, and bioink preparation, where biomaterials, bioactive molecules, and cells are combined. Processing involves the fabrication of cardiac constructs using various bioprinting modalities, including but not limited to droplet-based, extrusion-based, and light-based bioprinting. Post-processing focuses on tissue maturation through crosslinking, incubation, and maturation strategies such as bioreactor culturing. Created with BioRender.com. Abbreviation: CAD: Computer-aided design.

2.1. Pre-processing

Pre-processing involves all the preparatory steps necessary before the printing begins. First, the shape of the printed object is determined by computer-aided design (CAD) models, which can be manually designed or derived from medical imaging files, such as computed tomography or magnetic resonance imaging (MRI). Manually designed CAD models are generated directly within the software using basic modeling operations—such as sketching, extrusion, lofting, and cutting—to construct custom geometries without reliance on anatomical imaging sources. While manually designed CAD models are suitable for simple geometries such as strips, rings, and tubes, more anatomically complex models—such as valves, coronary arteries, and ventricles—are best generated from medical imaging data.15 Once an appropriate design is selected, a bioink that contains the necessary cellular and biomaterial components to support tissue function, can be selected.

2.1.1. Cells

The development, functionality, and maturation of cardiac tissue rely on a complex network of signaling and interactions among various cardiac cells.16,17 The major cardiac cell types—cardiomyocytes (CMs), endothelial cells (ECs), and cardiac fibroblasts (CFs)—comprise approximately 90% of the heart’s cellular population, while the remaining population includes vascular smooth muscle cells (VSMCs), immune cells, pericytes, adipocytes, and cardiac neurons.18 A summary of the major cardiac cells, their functions, and supporting cell types can be found in Figure 2.


Figure 2. Major and supporting cardiac cells. Cardiomyocytes are responsible for myocardial contractility and electrical conduction. Cardiac fibroblasts secrete ECMs and provide structural support. Endothelial cells line blood vessels, enabling vascularization and nutrient exchange. Vascular smooth muscle cells regulate vessel tone and allow arterial vasoconstriction/vasodilation. Supporting cell types, including pericytes, adipocytes, and macrophages, contribute to cardiac homeostasis and tissue remodeling. Created with BioRender.com. Abbreviation: EMC: Extracellular matrix.

For cardiac tissue engineering applications, pluripotent stem cells (PSCs), particularly induced pluripotent stem cells (iPSCs), are widely used due to their scalability and ability to differentiate into multiple cardiac lineages. While embryonic stem cells (ESCs) remain in use, iPSCs provide an ethical alternative, as they are derived and reprogrammed from somatic cells rather than embryonic tissue.19 During early cardiac engineering, CMs were once considered the only necessary cell type for functional cardiac tissue, resulting in efforts to prioritize optimizing PSC-CM differentiation and leading to a surge in protocols aimed at improving efficiency and reproducibility across multiple cell lines.20–22 Many bioprinted constructs have successfully generated contractile tissue using only iPSC/ ESC-derived CMs.23–32 Although CMs are critical for generating contraction and electrical signal propagation, CM interactions with non-myocyte populations are essential for functionality, as the absence of supporting cells compromises structural integrity, electromechanical function, and tissue longevity, and leads to pathological disruption. The sole focus of differentiation protocol development is no longer just on CMs; other cardiac cells—ECs in particular—are now receiving more attention.

Cardiac tissue is one of the most metabolically demanding tissues, requiring large amounts of oxygen and nutrient exchange to remain viable.33 To meet demands, cardiac tissue relies on dense vascular networks which are largely made up of ECs. Due to their availability and low cost, human umbilical vein endothelial cells (HUVECs) are commonly used in cardiac constructs. However, their venous phenotype limits their ability to form arterial vessels which are essential for effective vasculature.34–36 In contrast, PSC-derived ECs can differentiate into capillaries, arteries, and veins, making them essential for vascularization.37 In addition to ECs, VSMCs play a crucial role in regulating blood pressure and flow, maintaining vessel tone, and repairing injured arteries. PSC-EC and PSC-VSMC differentiation protocols are making swift progress in development, though not as abundant as CM protocols.38–41

While fibroblasts generally provide mechanical support and enable extracellular matrix (ECM) remodeling, CFs have specialized roles in heart tissue. They produce heart-specific ECM, secrete specific growth factors, and signaling molecules that promote CM alignment, maturation, and viability, regulate fibrosis to prevent excessive scarring, and are adapted to respond to cardiac-specific mechanical and electrical forces.42 Yet, many cardiac constructs continue to rely on primary CFs such as human dermal fibroblasts which lack the ability to perform the specialized tissue-specific tasks that CFs can.43–45 CF differentiation protocol development lags behind those of other major cardiac cells.46–48 Therefore, it is not uncommon to see bioink formulations using derived CMs and/or derived ECs with primary fibroblasts.49–54

Generally, using cardiac-derived cells is advantageous for situations where precise ratios of the major cardiac lineages are needed; however, completely recapitulating the native cardiac cellular composition remains challenging. Despite their relatively small populations, other cardiac cells, such as pericytes and macrophages, play critical roles in regulating major cell functions.55,56 However, differentiation protocols for these supporting cells remain limited, making their incorporation into a construct challenging. A potential solution involves differentiation protocols that simultaneously generate multiple cardiac lineages from early progenitors, like approaches commonly used in cardiac organoid development, which we will explore in later sections.

Beyond achieving the appropriate cellular composition, maintaining cardiac function during and after bioprinting requires recreating the biochemical and mechanical cues of the native environment. CM contractility and electrical propagation depend on alignment and gap junction formation, while ECs require signals that promote vessel formation and sustained metabolic activity. Fibroblasts and other stromal cells must also remain responsive to dynamic mechanical and biochemical inputs to preserve ECM structure and tissue organization. These functional attributes are supported not only by spatial patterning and biomaterial properties, but also by the incorporation of bioactive molecules that promote vascularization, matrix

remodeling, and CM maturation—factors that will be further explored in subsequent sections.

2.1.2. Bioink design

Unlike traditional 3D printing, which uses plastics or metals, bioprinting relies on bioinks—formulations that combine cells with biomaterials, and sometimes bioactive molecules, to fabricate 3D tissues. When designing a bioink, several key properties must first be considered to ensure successful fabrication and functional performance. Biocompatibility is essential for supporting cell viability, proliferation, and functionality without inducing cytotoxicity or immune responses. Printability determines the bioink’s ability to easily deposit while maintaining structural integrity after printing. In extrusion-based techniques, this requires shear-thinning properties, viscoelasticity, and controlled gelation kinetics to ensure smooth extrusion and post-printing architecture.57,58 In extrusion-based bioprinting, decreasing nozzle diameter improves resolution but increases pressure, which can reduce cell viability and lead to nozzle clogging. Optimizing bioink formulations—along with adjustments to printing parameters such as pressure, speed, and nozzle size—has been shown to enhance structural fidelity without minimizing shear stress-induced damage.59,60 For non-extrusion techniques, bioinks should have low viscosity to prevent nozzle clogging and improve deposition accuracy.

Mechanical properties must be optimized to mimic myocardial stiffness (8–17 kPa) to provide structural support and biomechanical cues essential for cardiac function.61 Additionally, bioinks must maintain adequate porosity to facilitate nutrient and oxygen diffusion throughout the construct. Biodegradability should be tuned to match the rate of tissue remodeling, ensuring that the scaffold provides support without premature degradation. Lastly, bioactivity is crucial for mimicking the cardiac ECM, by promoting cell attachment, proliferation, differentiation, and angiogenesis, all of which contribute to tissue function and maturation.57,59 Achieving these ideal bioink properties requires careful selection of appropriate biomaterials that balance biocompatibility, mechanical support, and biological signaling.

Hydrogels, which are 3D crosslinked polymer networks that retain water and mimic the ECM, are among the most widely used biomaterials for cardiac tissue engineering.62 These hydrogels can be composed of natural, synthetic, or hybrid polymers, each of which offers unique properties for cardiac tissue engineering. Natural biomaterials are derived from biological sources and are favored for their high biocompatibility and ability to mimic the ECM. Commonly used natural biomaterials for cardiac applications include alginate, decellularized extracellular matrix (dECM), and ECM components such as collagen, fibrin, gelatin, and Matrigel®, which are summarized in Table 1.

Table 1. Summary of biomaterials and bioactive molecules commonly used in cardiac bioprinting

Biomaterial/biomolecule Type Key properties/functions References
Alginate Natural biomaterial Biocompatible, easy gelation; used as a hydrogel scaffold to support cell encapsulation 34,35,77
Collagen Natural biomaterial Natural ECM component with RGD motifs; promotes cell attachment and tissue remodeling 24,88
dECM Natural biomaterial Retains native cardiac ECM composition with proteins and GAGs; recreates physiological microenvironment 54
Fibrin Natural biomaterial Pro-angiogenic, supports vascular network formation and myocardial regeneration 34,53,67
Gelatin Natural biomaterial ECM-mimicking; often modified to enhance printability and mechanical strength 67
GelMA Natural biomaterial (modified) Photocrosslinkable and bioactive; enables engineering of structured tissues 23,25,32,35,51,89–91
Matrigel® Natural biomaterial Rich in ECM proteins and growth factors; supports early cardiac tissue formation 88
PEG Synthetic biomaterial Highly tunable mechanical properties, bioinert polymer; used for creating customizable, hydrogel scaffolds 34
PEGDA Synthetic biomaterial (modified) PEG derivative with acrylate groups; allows photocrosslinkable hydrogel formation 51,77
VEGF Bioactive molecule Growth factor; stimulates EC proliferation and vascularization *
FGF Bioactive molecule Growth factor; Promotes fibroblast and EC development for tissue remodeling *
TGF-βi Bioactive molecule Modulate fibrosis and promote epicardial and fibroblast lineage specification *

*Used in media not bioink formulation

Abbreviations: dECM: Decellularized extracellular matrix; ECM: Extracellular matrix; FGF: Fibroblast growth factor; GAG: Glycosaminoglycan; GelMA: Gelatin methacryloyl; PEG: Polyethylene glycol; PEGDA: Polyethylene glycol diacrylate; RGD: Arginylglycylaspartic acid; TGF-βi: Transforming growth factor beta inhibitor; VEGF: Vascular endothelial growth factor.

Alginate is a naturally occurring polysaccharide that is highly biocompatible with a multitude of cells and other biomaterials. Alginate is used for a variety of biomedical applications due to its gelation properties and ease of modification.63 Derived from brown algae, alginate does not have naturally occurring cell-binding sites and must be modified with adhesive ligands to promote cell attachment.62 Alginate is often described as a blank slate biomaterial, making it particularly useful for maintaining the current cellular state. Collagen is the most abundant component of the ECM. As a bioink, collagen is commonly used due to its high biocompatibility, presence of cell-attachment-encouraging Arginylglycylaspartic acid (RGD) cell binding sites, enzymatic degradability, and temperature-dependent gelation.64 However, its low mechanical strength remains a significant limitation, especially for bioprinting.65 Fibrin, a protein involved in the coagulation cascade, has been utilized in bioprinting due to its applications in wound healing and its intrinsic angiogenic properties.66 Fibrin- based biomaterials facilitate the proliferation and spreading of multiple cardiac cells.67–69 Gelatin is a derivative of collagen that retains collagen’s biocompatibility, biodegradability, and ability to mimic the ECM.62 Like collagen, it is widely used in bioprinting despite its limited mechanical properties and is often modified to improve printability. Decellularized ECM-based bioinks are the most effective at recapitulating native tissues’ complex composition of proteins, glycosaminoglycans, proteoglycans, and other cardiac components.70 Decellularization techniques use chemical, physical, and/or biological agents to remove cells and immunogenic components, leaving behind a supportive scaffold for promoting cell adhesion, proliferation, migration, and differentiation.58 Matrigel® and other similar basement membranes such as Geltrex® and Cultrex® are widely utilized in both 2D and 3D cultures.71 They are highly compatible with cells due to their composition of ECM components such as laminin, collagen type IV, entactin, and heparan sulfate proteoglycans, and growth factors like transforming growth factor beta (TGF-β) and fibroblast growth factor (FGF). Batch variability, weak mechanical properties, and risk of inducing tumorigenicity limit Matrigel® bioink formulations.72,73

Chemically modifying natural biomaterials can improve certain properties. For example, the addition of methacrylate groups (–CH=CH2) can allow some biomaterials to become photocrosslinkable. Gelatin methacrylate (GelMA), also known as gelatin methacryloyl, is synthesized by reacting the primary amine (–NH2) and hydroxyl (–OH) groups of the gelatin with methacryloyl groups (–CO–CH=CH2) from methacrylic anhydride (C4H6O3). Like collagen, GelMA mimics the native ECM and promotes cell attachment, proliferation, and differentiation. However, GelMA offers superior printability due to its ability to be crosslinked by light and its tailorable mechanical properties.74 GelMA is often used in combination with other biomaterials to provide additional pro-regenerative stimulation through biological signals necessary for proliferation, differentiation, and other cell- to-cell interactions, and improve both printability and mechanical stability.23,35,70

Synthetic biomaterials offer several advantages in bioprinting. Their tunable chemical structure allows for precise control over degradation rates, mechanical properties, and crosslinking kinetics. They also exhibit excellent batch-to-batch consistency, long-term storage stability, and scalability for manufacturing applications. Furthermore, synthetic polymers can be readily functionalized with peptides, growth factors, or chemical groups to enhance cell adhesion and bioactivity. However, challenges including toxic byproducts, poor cell encapsulation, and a lack of natural adhesion sites limit their usage.75 Additionally, many synthetic polymers are inherently brittle and lack the elasticity required to replicate the biomechanical properties of the native myocardium.9 An exception to many of these limitations is polyethylene glycol (PEG), a polymer widely used in bioprinting and 3D culturing due to its hydrophilicity, tunability, and biocompatibility.75,76

Modified synthetic bioinks such as PEG hybrids are more widely used than pure synthetics in bioprinting. PEG-diacrylate (PEGDA), a PEG derivative commonly utilized for cardiac bioprinting, is capable of ultraviolet (UV) or visible light crosslinking due to the replacement of PEG’s hydroxyl (–OH) end groups with acrylate (–C=C–COO–) groups, enhancing structural stability.77,78 Cell adhesion-enhancing RGD peptides have been used to functionalize synthetic hydrogels and promote cardiac tissue formation.79,80 However, it is more common for researchers to employ hybrid bioink formulations of both natural and synthetic biomaterials to achieve bioinks with good printability and biocompatibility.

Beyond optimizing material composition alone, incorporating bioactive molecules into bioinks offers an additional strategy to guide cell behavior, promote differentiation, and enhance vascularization. While they are not always included in bioink formulations, bioactive molecules are critical for cardiac tissue engineering as they regulate cell attachment, proliferation, differentiation and maturation.

While early-stage differentiation factors such as CHIR99021(Chir)—a glycogen synthase kinase 3β inhibitor that triggers mesodermal induction of stem cells into progenitors—are difficult to incorporate due to concentration and timing sensitivities, later-stage growth factors such as vascular endothelial growth factor (VEGF) have been successfully encapsulated within hydrogels to support endothelialization and vascularization.38,39,81–83 Studies on controlled VEGF release from gels support the notion that VEGF is capable of supporting cellular proliferation and migration of encapsulated cells.84,85 These findings have contributed to the emergence of commercially marketed VEGF bioinks such as Sigma- Aldrich’s INVIVO-GEL VEGF and Amerigo Scientific’s Gel4Cell®-VEGF.

FGF and TGF-β inhibitors (TGF-βi), while not yet incorporated into commercial bioinks, have also been used to functionalize biomaterials and guide differentiation toward epicardial and fibroblast lineages.46–48,86,87 As the field progresses toward more heterogeneous constructs, controlled delivery of differentiation signals will likely become an essential component of next-generation cardiac bioinks.

2.2. Processing

To fabricate functional in vitro cardiac models, it is essential to balance structural precision, biomaterial selection and print fidelity. However, several processing challenges must be addressed to ensure the long-term viability, maturation, and functionality of engineered cardiac tissues. These include achieving physiological cell densities, maintaining mechanical stability, replicating anisotropic architectures, and integrating vascular networks (Figure 3).


Figure 3. Goals and challenges in engineering cardiac tissues. Engineering functional cardiac tissues require addressing several key challenges: achieving physiological cellular densities to enable proper electrical coupling and contraction; maintaining mechanical stability in macroscale constructs to preserve shape and function; replicating the anisotropic architecture of native myocardium to support directional signal propagation and coordinated contraction; and integrating vascular networks to supply oxygen and nutrients beyond the diffusion limit. Created with BioRender.com.

Bioprinting is broadly categorized into three modalities—extrusion-based bioprinting (EBB), light-based bioprinting (LBB), and droplet-based bioprinting (DBB), each offering distinct advantages in overcoming these challenges. These techniques have enabled the fabrication of a wide range of cardiac structures including patches, engineered muscle tissues, valves, chambers, and miniature whole-heart models.24,25,32,34,49–51,53,54,67,68,77,88–91

EBB continuously deposits high-viscosity bioinks using pneumatic pressure, pistons, or screw-driven forces, enabling high-cell-density, macroscale cardiac tissues. This technique is widely used for patches, engineered cardiac tissues, and other large-scale cardiac constructs, although it struggles with microarchitectural fidelity and microscale vascularization.92

LBB uses patterned light exposure to crosslink photoactive bioinks into 3D structures. Projection-based LBB techniques such as digital light processing (DLP) and volumetric bioprinting, enable high-resolution cardiac tissue fabrication and excel fabrication of microvasculature, patterned cellular and biomaterial alignment, and intricate cardiac architectures. However, they lack scalability and require specific bioink formulations that limit their versatility.93,94

DBB ejects discrete, cell-laden droplets via thermal, piezoelectric, or electromagnetic forces, making it ideal for high-precision cardiac cell patterning, endothelialization, and disease modeling. However, its reliance on low- viscosity bioinks limits structural stability, making it unsuitable for printing large or thick cardiac tissues.95

Table 2 summarizes the key characteristics of the primary bioprinting modalities, highlighting their deposition mechanisms, resolution, speed, bioink compatibility, and major advantages and limitations. This section explores how these distinctions within each modality address key structural, cellular and functional challenges in cardiac engineering.

Table 2. Cardiac bioprinting modalities

Modality Deposition mechanism Resolution Speed Bioink compatibility Advantages Limitations
EBB Continuous deposition of high-viscosity bioinks using pneumatic, piston, or screw-driven extrusion 200–1000 µm Slow–moderate Wide range (natural, synthetic, hybrid) High-cell-density printing, scalability, multimaterial printing Limited resolution, poor microscale vascularization, shear stress-induced cell damage
LBB94,96 Patterned light exposure to crosslink photoactive bioinks 10–50 µm (DLP) < 10 µm (μCOP) Fast Requires photoactive bioresins High resolution, patterned microvasculature, anisotropic tissue alignment Limited scalability, bioink restrictions, cytotoxicity (UV light exposure)
DBB95 Discrete bioink droplet ejection via thermal, piezoelectric, or electromagnetic forces 10–50 µm Fast Low-viscosity bioinks High precision for cell patterning, endothelialization Low structural stability, unsuitable for bulk tissue fabrication

Abbreviations: DBB: Droplet-based bioprinting; DLP: Digital light processing; EBB: Extrusion-based bioprinting; LBB: Light-based bioprinting; μCOP: Micro-continuous optical printing; UV: Ultraviolet.

2.2.1. Achieving physiological cellular density

The adult heart has an average cellular density of 30–40 million cells/mL.97 Direct cell–cell contact is a critical factor for CM differentiation and synchronized electrical propagation; therefore, matching these densities is critical to achieving functional constructs. Some studies have aimed to directly match bioink’s formulation to the heart’s cellular density prior to printing while others have relied on the proliferation of stem cells to reach confluency within the printed construct post-printing.23,88,98 Achieving these densities in constructs can pose a significant challenge. EBB is best suited for high-cell-density bioprinting, able to handle bioinks ranging from 106–108 cells/mL, whereas DBB can only handle around 106 cells/mL and LBB 106–107 cells/mL. Additionally, EBB can handle high- viscosity bioinks, including hydrogels which are optimal for cell encapsulation. However, printing at high density is not without tradeoffs. Both high biomaterial viscosity and high cell density increase the mechanical resistance of bioinks when extruded. The combination of the two significantly increases the amount of stress exerted on the cells. PSCs are particularly susceptible, often experiencing cell death, unintended differentiation, or loss of pluripotency.60 Mitigating shear stress-induced damage requires a balance of optimizing printing parameters such as extrusion pressure, nozzle diameter, and bioink viscosity. In contrast, LBB and DBB require low-viscosity bioinks to prevent light-scattering issues in LBB and nozzle clogging in DBB.98 As a result, LBB and DBB printers tend to report higher cell viability than EBB methods.

2.2.2. Maintaining mechanical stability in macroscale prints

Cardiac tissue engineering has yet to achieve clinical relevance, in part due to the inability to fabricate large-scale constructs with physiologically relevant architecture. For this review, a large-scale construct refers to a tissue model with physical dimensions greater than 1 cm³. While smaller constructs provide valuable insight into cellular behaviors and function, scalable macroscale tissues will be essential for functional grafts and physiologically relevant in vitro models. However, shifting from microscale to macroscale bioprinting introduces mechanical and structural challenges, including deformation, poor printability, and mismatched mechanical properties.

Low-viscosity bioinks lack mechanical strength, making large-scale printing difficult with LBB or DBB. This limitation positions EBB as the most suitable modality for printing macroscale cardiac constructs. While high- viscosity bioinks improve shape fidelity upon deposition, soft tissues—including cardiac tissue—often exhibit poor shape retention post-extrusion. The mechanical properties of many bioinks are insufficient to maintain complex geometry, leading to sagging or deformation in unsupported regions.49,99

Additionally, the inherently slower printing speed of EBB—commonly reported in the range of ~5–25 mm/s for cardiac applications—further limits its efficiency in producing high-fidelity, large-scale tissues.49,57,77,88 To address these issues, researchers have developed support bath techniques to improve print fidelity. One such method is the freeform reversible embedding of suspended hydrogels (FRESH), which temporarily suspends soft bioinks in a thermoreversible gelatin bath to stabilize structures during deposition.99 By preventing structural collapse, FRESH enables the fabrication of complex architectures that would otherwise fail under traditional extrusion bioprinting. This approach has enabled the successful bioprinting of small coronary artery models, heart tubes, tri-leaflet valves, ventricle-like constructs, and even a full-sized adult heart model.49,88,99,100

Another strategy for improving structural reinforcement involves multi-material bioprinting. Although tunable hybrid bioinks such as GelMA-PEGDA provide mechanical improvements, printing with separate biomaterials in distinct regions of a construct offers additional advantages. For instance, sacrificial bioinks have been used to provide temporary structural support, allowing for the formation of hollow or intricate geometries that are later cleared. This technique is particularly useful when support bath methods are not feasible.49,101

Until recently, EBB held the sole advantage in multi-material bioprinting due to its ability to integrate multiple print heads, each of which dispenses distinct bioinks to designated regions within a construct. This capability enables the replication of heterogeneous cardiac tissue composition, improving biomimetic accuracy. However, recent advancements in DLP-based LBB have expanded multi-material capabilities, with printers that allow rotating platforms to switch between multiple bioink reservoirs.102 Concurrently, research into photoactive bioinks continues to expand the range of materials compatible with DLP, including ECM, collagen, GelMA, hyaluronic acid (HA), and PEG/PEGDA blends.51,90,103–105

While maintaining structural integrity is critical, excessive stiffness can also negatively impact physiological function. The elastic modulus of the myocardium (~8–17 kPa) not only enables contraction but also plays a role in cardiac differentiation.61 Constructs that deviate significantly from this range may fail to develop properly, integrate with native tissue, or in extreme cases, exacerbate myocardial damage. Thus, tuning stiffness and elasticity through the manipulation of printing parameters—rather than material composition—can enhance structural fidelity while preserving biomechanical properties necessary for functional cardiac constructs. Several bioprinting properties influence construct stiffness. Adjusting pressure, nozzle diameter, and flow rate not only modulates construct stiffness but also impacts cell viability and resolution. Additionally, fine-tuning layer thickness and print infill patterning increase overall stiffness, albeit in a more gradual manner. Izadifar et al.106 demonstrated that changing interstrand distances (300, 900, and 1500 µm) and strand alignment angles (0°, 45°, 90°, and 135°) in printed constructs influences not only elastic modulus but also porosity and electrical conductivity. Optimizing construct porosity is crucial for oxygen and nutrient exchange, highlighting how spatial patterning can be leveraged to enhance both mechanical strength and biological outcomes in engineered tissues.106

2.2.3. Structuring anisotropic cardiac architectures

The electrical and mechanical function of the heart is highly dependent on the anisotropic properties of the myocardium, a complexity that remains a major challenge to replicate. At the cellular level, the alignment of the CMs, which are interconnected by gap junctions, allows rapid, unidirectional electrical signal propagation and synchronized contraction.107 At the tissue level, ECM fibers—predominantly collagen—form structured networks that guide cell alignment, facilitate mechanotransduction, and transmit contraction forces throughout the myocardium. Failure to capture both ECM and myofiber anisotropy can impair electrical conduction and weaken the contraction forces of engineered cardiac tissues.107,108 At the organ level, muscle layers form aligned sheets in a helical arrangement, which gives the ventricles their twisting motion during contraction (Figure 4). Failure to incorporate this architecture can result in lower ejection fractions in chamber models.109


Figure 4. Architecture and anisotropy of cardiac tissue across cellular, tissue, and organ levels. At the cellular level, cardiomyocyte alignment and gap junction connectivity enable unidirectional electrical propagation. ECM fibers and organized myocyte sheets facilitate coordinated mechanical contraction at the tissue level. At the organ level, the helical fiber orientation of multiple layers of the myocardium enables efficient torsional movement during ventricular contraction. Created with BioRender.com. Abbreviation: ECM: Extracellular matrix.

Bioprinting has expanded the ability to control cellular and fiber alignment, bringing engineered tissues closer to replicating the anisotropic nature of native myocardium. Given the unique mechanisms of each modality, researchers have used different approaches to recreate the heart’s architecture based on the individual strengths of different printing modalities.

Recent studies have demonstrated that shear stress-induced alignment combined with nozzle shape optimization and print speed manipulation significantly enhance ECM fiber alignment during EBB. By increasing print speeds to over 2000 mm/min and adjusting the printing pressure, Bera et al.108 directed cells to orient along the printing path, producing patches with aligned ECM fibers that revealed significant improvements in contractility and signal propagation, as evidenced by upregulated expression of contractility genetic markers and intercalated disc formation. Despite successful instances of EBB replicating anisotropy, its ability to fully replicate fine-scale anisotropic features seen in native tissue is severely limited by its low resolution (200–1000 µm).

Both DBB and LBB provide significantly higher resolutions (10–50 µm) compared to EBB. However, DBB’s practical application is restricted by the mechanical properties of its bioink. Due to reliance on low-viscosity hydrogels and cell suspensions, DBB struggles to print large-scale, 3D constructs. This limitation confines its use to thin cardiac sheets and microtissues.110–112

Among LBB techniques, micro-continuous optical printing (μCOP), a subset of DLP achieves even finer resolutions (<10 µm), enabling rapid generation of highly aligned tissue fibers.51,103 Unlike approaches that rely on post-printing cell seeding, μCOP enables direct cellular encapsulation within photopolymerizable hydrogels, ensuring strong initial alignment. μCOP techniques have reported significant enhancement of contractility. Liu et al.103 reported a four- to ten-fold increase in contractile force of aligned constructs compared to 2D-seeded prints.

2.2.4. Integrating vascular networks into bioprinted constructs

To sustain thick cardiac tissues, integrated vascular networks are essential for providing oxygen and nutrients beyond the diffusion limit (200 µm).113 Without perfusable vascularization, engineered constructs are prone to hypoxia and necrosis, restricting the size of viable tissues. Several bioprinting strategies have been developed to incorporate multiple scales of vascular structures, ranging from large perfusable vessels to microcapillary networks (Figure 5).


Figure 5. Vascularization strategies for bioprinting cardiac tissues. (A) Overview schematic of techniques used to incorporate vessels and vascular networks into cardiac constructs, including direct vessel printing, sacrificial bioink-based approaches, and endothelial cell-guided self-assembly. Created with BioRender.com. (B) Hinton et al.99 used direct printing and a 3D MRI scan of a right coronary arterial tree (left) to fabricate large-scale vessels within alginate prints in gelatin support baths (right). (C) Maiullari et al.34 compared cardiomyocyte expression markers TNNI (red) and Cx43 (green) and HUVEC expression vWF (green) in prints using different printing geometries to determine the effect of cellular spatial arrangement on de novo vessel formation. (D) Noor et al.54 created a 3D model of a cardiac patch using sacrificial ink (left) to print a cardiac patch with channels, which form a vascular pattern (right). Panels B, C, and D were adapted from refs. 99, 34, and 54, respectively, under Creative Commons Attribution 4.0 International (CC BY 4.0). Abbreviations: CMs: Cardiomyocytes; EC: Endothelial cell; HUVEC: Human umbilical vein endothelial cell; MRI: Magnetic resonance imaging; OM+CM: Omentum + Cardiomyocytes; vWF: von Willebrand factor.

One approach to integrating vascular networks into bioprinted constructs is to directly print vessels within cardiac constructs. Hinton et al.99 used EBB and FRESH to fabricate coronary arterial trees with internal lumen diameters ranging from 1 to 3 mm and a wall thickness of less than 1 mm. However, when perfusion tests were conducted, they needed to use an external fixture to maintain mechanical stability during the experiment, highlighting the challenges in balancing structural stability with perfusability in directly printed vessels.99 Jia et al.91 used coaxial extrusion to easily create hollow tubes to create vascular of various dimensions. By adjusting the gauging of both the inner and outer needles, they created a diverse range of vessels with inner diameters (400–1000 µm), outer diameters (500–1500 µm), and wall thicknesses (60–280 µm). They proceeded to print an 8 × 9 × 7 mm, 10-layer construct using hollow fibers, producing a completely perfusable construct that demonstrated no rupturing or collapsing.91 The direct printing enables large- scale vessel formation but lacks the resolution needed to form capillary networks, which are critical for cardiac tissues considering every CM has contact with at least one capillary, due to the high demand for nutrients needed for cardiac contraction.16

Another strategy is to print and then remove sacrificial bioink-formed vascular networks leaving behind channels. This approach allows finer-scale vessel formation. Skylar-Scott et al.101 developed the Sacrificial Writing into Functional Tissues (SWIFT) specifically for creating perfusable vascular channels in thick tissues. Using this method, they were able to create channels with a diameter of 400–1 mm within high-density constructs. Lee et al.49 used a similar approach, by embedding and then melting out gelation microparticles in small FRESH-printed collagen discs, creating capillary-sized (~25 μm diameter) pores.

Rather than directly printing vessels or channels, another approach is to promote the natural formation of vasculature through EC patterning and guided self-assembly. Prior to implanting the collagen discs, Lee et al.49 added fibronectin and VEGF to enhance vascularization. When compared to controls, host-derived vessels (8–50 μm) were only observed in printed constructs, demonstrating that bioprinting can guide in vivo vascularization. Maiullari et al.34 used manipulation of cell spatial arrangements to enhance vascularization. Using an alternating layer arrangement of iPSC-CM and HUVECs, they were able to generate vessel-like structures (~150 μm lumen diameter) more effectively than with other spatial arrangements.

Table 3 presents a selection of representative cardiac bioprinting studies that employ different modalities, materials, and construct types. While not exhaustive, these examples illustrate key advances and diversity in cardiac bioprinting approaches.

Table 3. Modalities, materials, and construct types used in bioprinting of cardiac constructs

Modality Design Biomaterials Cells Key outcomes References
Extrusion Engineered cardiac tissue GelMA Laminink-521 iPSC-CMs Developed a patient-derived bioprinted patch for CHD modeling 25
Extrusion (coaxial) Engineered cardiac tissue Alginate, PEG- fibrinogen, CaCl2 solution iPSC-CMs, HUVECs Coaxial bioprinting of vascularized cardiac patches with endothelialized microchannels 34
Extrusion Cardiac patch Omentum-derived dECM hydrogel iPSC-CMs, iPSC-ECs Created for the first fully personalized, thick, and perfusable patches 54
Extrusion Engineered cardiac tissue Omentum-derived dECM hydrogel iPSC-CMs, iPSC-ECs Developed thick vascularized cardiac tissues with perfusable triaxial lumens 54
Light (DLP) Engineered cardiac tissue GelMA hPSC-pacemaker cells Bioprinted a pacemaker-like construct capable of pacing a hPSC-CM laden “Mini Heart” model 89
Light (DLP/μCOP) Engineered cardiac tissue GelMA, PEGDA, H54AGM iPSC-CMs, human CFs Alignment cues used to develop cardiac microtissues for high-throughput drug testing 51
Extrusion Engineered heart tissue Collagen, Matrigel® iPSC-CMs, CFs Printed a heart tube model 88
Extrusion Engineered heart tissue Fibrinogen hiPSC-CMs, hiPSC-ECs, primary adult ventricular human CFs Aligned, high-cellular-density cardiac tissue produced in highly reproducible format (24-well plate) 53
Extrusion Engineered cardiac tissue GelMA, collagen iPSC-CMs from healthy and CPVT patients First functional printed CPVT patient-specific model 32
Light (DLP/ μCOP) Engineered cardiac tissue GelMA hESC-CMs GCaMP3-hESC-CMs* printed into patterned hydrogels for simultaneous force and calcium readouts 90
Extrusion Engineered heart tissue GelMA/ColMA hiPSCs → hiPSC-CM First macroscale, perfusable two-chambered heart model 23
Extrusion Engineered Heart tissues Collagen/hyaluronic acid hiPSC-CMs Directly bioprinted beating ring and ventricle constructs 24
Extrusion Engineered cardiac tissue Collagen iPSC-CMs Bioprinted high-fidelity heart components across multiple scales: perfusable vascular networks, tri-leaflet valves, left ventricle model, neonatal-scale whole human heart (two-chambered) 49
Extrusion Valve PEGDA, alginate Porcine aortic valve interstitial cells Printed anatomically accurate, and mechanically heterogeneous aortic valves 77
Extrusion (coaxial) Vascular constructs GelMA, PEGTA HUVECs, iPSC-derived ECs Single-step direct bioprinting of perfusable, multi-layered vascular constructs with tunable lumen geometry 91
Extrusion Engineered cardiac tissue Fibrin, gelatin iPSC-CMs, CFs Demonstrated connexin 43 mediated electrical coupling and myocardium- matched stiffness via dual crosslinking 67
Extrusion Engineered cardiac tissue GelMA–alginate hiPSC-CMs, HUVECs Developed an anisotropic, endothelialized myocardium-on-a-chip model for drug cardiotoxicity evaluation 35

*GCaMP3 is a calcium indicator.

Abbreviations: CaCl2: Calcium chloride; CFs: Cardiac fibroblasts; CHD: Congenital heart disease; ColMA: Collagen methacrylate; CPVT: Catecholaminergic polymorphic ventricular tachycardia; dECM: Decellularized extracellular matrix; DLP: Digital light processing; GelMA: Gelatin methacrylate; H54AGM: Glycidyl methacrylate-hyaluronic acid; hESC-CMs: Human embryonic stem cell-derived cardiomyocytes; hiPSCs: Human induced pluripotent stem cells; hPSC: Human pluripotent stem cells; HUVECs: Human umbilical vein endothelial cells; iPSC-CMs: Induced pluripotent stem cell-derived cardiomyocytes; iPSC-ECs: Induced pluripotent stem cell-derived endothelial cells; μCOP: Micro-continuous optical printing; PEG: Poly(ethylene glycol); PEGDA: Poly(ethylene glycol)-diacrylate; PEGTA: 4-arm poly(-ethylene glycol)-tetra-acrylate.

2.3. Post-processing

Post-processing is essential for transforming initial prints into structurally stable and functionally mature tissue. Without post-printing modifications, engineered tissues often lack mechanical strength, mature electromechanical activity, and sufficient vascularization for physiological function. Common post-processing strategies include crosslinking for mechanical stabilization and functional conditioning to promote cellular maturation.

Crosslinking, the process of forming bonds within a bioink polymer network, is a critical step in bioprinting to maintain structural integrity and enhance mechanical stability. Choosing a crosslinking strategy influences the mechanical properties, biocompatibility, and degradation of the printed construct. Crosslinking can be divided into physical and chemical techniques, with the most commonly used techniques including photocrosslinking, ionic crosslinking, thermal, and enzymatic crosslinking.114–117

Physical crosslinking techniques—such as ionic and thermal crosslinking—use changes in external stimuli to induce non-covalent bonding in the polymer chains of the biomaterial. Ionic crosslinking relies on multivalent cations to induce gelation. The most common ionic crosslinker ion in bioprinting is calcium, which is frequently applied in alginate-based bioinks. 63,115 Other ionic crosslinkers, including barium chloride (BaCl2) and zinc chloride (ZnCl2), have been tested for their influence on the mechanical and biological properties post-crosslinking; however, BaCl2 had biocompatibility concerns while ZnCl2 resulted in cytotoxic effects.118 Other calcium-based crosslinkers include calcium sulfate (CaSO4) and calcium carbonate (CaCO3), which offer slower Ca²+ release potentially leading to more uniform and controlled crosslinking but are often not utilized because CaCl2 offers a faster, simpler, and well-established solution.116,119 Although rapid and highly biocompatible, CaCl2-crosslinked constructs tend to be mechanically weaker, limiting their long-term structural stability.

Thermal crosslinking involves temperature-dependent gelation of thermosensitive polymers such as collagen, gelatin, GelMA, and Pluronic F127.117,120 While operationally straightforward, effective thermal crosslinking can be challenging due to a lack of ability to precisely control the degree of crosslinking through temperature shifting alone. Furthermore, some materials can take minutes or hours to thermally crosslink but seconds with alternative methods. The temperature at which a biomaterial crosslink is based not only on the material type but also on other factors such as concentration. For example, the percentage at which GelMA is reconstituted determines the temperature needed to induce gelation. 10% GelMA—commonly used in bioink formulations—gels around 23°C, while GelMA of higher concentrations, such as 15%, gels at 27°C.120 Thermally crosslinked constructs exhibit low mechanical strength, which explains their relatively short-term stability. However, this short-term stability is often taken advantage of to produce sacrificial bioinks and temporary support baths/structures as previously described.53,54,88,100,101 In general, physical crosslinking techniques are weaker than chemical techniques and are often reversible.

Chemical crosslinking, on the other hand, forms covalent bonds between polymer chains, which are stronger and often permanent. These techniques are particularly important for long-term structural stabilization. Photocrosslinking, the most common crosslinking strategy employed in cardiac bioprinting, uses light exposure to initiate polymerization in bioinks containing photoinitiators, making it a widely applicable technique across EBB, LBB, and DBB. The most common photoinitators in bioprinting are Irgacure-2959, lithium phenyl-2,4,6-trimethylbenzoylphosphi-nate (LAP), and eosin Y. Irgacure and LAP are UV l-activated crosslinkers, typically excited at 365 or 405 nm, enabling rapid gelation and tunable mechanical properties.114 However, UV light can be cytotoxic, reducing cell viability within printed constructs. As an alternative, visible light crosslinking systems—such as Eosin Y in combination with initiator triethanolamine, and catalyst 1-vinyl-2 pyrrolidinone—have been developed to minimize cell damage while maintaining effective crosslinking.67,121

Enzymatic crosslinking is another common type of chemical crosslinking that uses enzymes—commonly, transglutaminase and horseradish peroxidase—to induce gelation in a gentler but highly specific reaction. Although it has higher biocompatibility, is tunable and allows in situ crosslinking, its slow gelation and sensitivity to environmental conditions such as oxygen, pH, and temperature can be limiting.115,122,123

Some researchers are using hybrid crosslinking approaches to improve structural fidelity without sacrificing biocompatibility.67,91,122,123 Basara et al.122 used photocrosslinking and enzymatic crosslinking to model myocardial infarct boundaries where the stiffness of healthy cardiac tissue (8–12 kPa) and scar tissue (>150 kPa) meet. UV light was used to rapidly crosslink a GelMA–MeHA–dhECM bioink, which under normal conditions tends to be mechanically weak after printing. After the initial crosslinking, they use microbial transglutaminase (mTGase) to further crosslink the gels, resulting in tissues with stiffness ten times greater than GelMA controls, allowing them to mimic both healthy and fibrotic tissue.122 Contrary to Basara et al.’s dual techniques that used both crosslinking techniques after printing, it is possible to use crosslinking prior to printing. Budharaju et al.123 combined ionic and enzymatic crosslinking to enhance shape fidelity, printability, and mechanical strength of alginate–fibrinogen-based myocardial patches. First, CaCl2 was used to pre-crosslink the alginate prior to printing, resulting in gelation suitable for extrusion without inducing nozzle clogging and significant improvement of shape fidelity and print resolution. Once the constructs were printed, additional CaCl2 was used to fully crosslink the alginate along with thrombin which was used to crosslink the fibrinogen. This dual crosslinking completed the mechanical stabilization of the constructs, with hybrid crosslinking demonstrating slower degradation rates than single crosslinked controls.123

Although crosslinking strategies ensure long-term mechanical integrity, structural stabilization alone is insufficient for generating fully functional cardiac tissues. Physiological conditioning is essential for CM maturation, synchronized electrical activity, and functional vasculature. To achieve this, researchers employ mechanical loading, electrical stimulation, and perfusion techniques to replicate the native cardiac environment and enhance long-term tissue viability.

The heart is constantly subjected to mechanical stress due to continuous myocardial contraction, which plays a critical role in CM development and maturation.124In vitro, tissue stretching or compression has been used to simulate these mechanical forces, leading to increased sarcomere lengths, larger cell area, elongation, improved calcium handling, and greater expression of sarcomere, ion channel, and maturation-related genes.125,126 Furthermore, mechanical stimulation enhances CMs alignment, showing cyclic stress is more effective than static stress, likely due to its rhythmic nature, matching that of the heart.127

Electrical stimulation is also a widely used strategy for enhancing the maturation of engineered cardiac tissues. Electrical stimulation has been shown to accelerate sarcomere organization, enhance calcium handling, and upregulate electrophysical gene expression.128,129 Notably, a gradual increase in stimulation is more effective over time than maintaining a fixed pacing rate.129,130 Emerging approaches, such as mechanical and electrical stimulation, advanced bioreactor systems, and machine learning-based bioink optimization, show promise for improving cell maturation, vascularization, and tissue endurance.125,131

Beyond mechanical and electrical conditioning, pulsatile perfusion plays a dual purpose in post-processing. It enhances cell survival by continuously supplying nutrients and removing metabolic waste while simultaneously delivering biomechanical cues to stimulate CM maturation. Additionally, flow-induced shear stress promotes EC alignment, further enhancing vascularization.131,132

While each of these conditioning strategies has been shown to enhance tissue function individually, their combined application can have a compounding effect, significantly improving overall tissue maturation. As a result, bioreactors are becoming indispensable in post-processing, allowing for simultaneous integration of multiple conditioning techniques, effectively replicating the complex and dynamic physiological environment of the native heart.131–133

Bioprinting has enabled the fabrication of diverse structured cardiac tissues, advancing in vitro modeling beyond 2D culture, animal models, and conventional 3D cultures. However, while bioprinting allows precise spatial control over tissue structures, it does not fully capture the developmental self-organization inherent to natural heart development. Cardioids, or cardiac organoids, represent a promising model that leverages biological self-organization to recapitulate aspects of early heart development. These models recapitulate key aspects of early heart formation, including cellular diversity and functional mimicry, providing valuable insights into cardiac biology.12–14 Integrating bioprinting with cardioid technology may provide a hybrid approach, combining biological self-organization with engineered structural guidance to enhance scalability, vascularization, and maturation. The following section will explore the fundamental characteristics of cardioids, their applications in cardiac research, and their current limitations.

3. Cardioids: features, applications, and limitations

Cardioids, or cardiac organoids, are self-organizing, 3D heart tissues that model aspects of early heart development in vitro. Historically, the term “cardiac organoid” was first used in a 2001 study by Zimmerman et al.,11 who cast neonatal myocytes and collagen type I into circular molds to generate a contractile cardiac construct.

The observation of self-organization post-fabrication and the presence of non-myocyte populations led the authors to label their construct as “organoid-like.”11 Broadly, the term “organoid” has been used loosely and interchangeably with several other terms referring to 3D cultures—such as microtissues, assembloids, and spheroids, and engineered heart tissues—yet there are universally agreed upon features that all organoids, including cardioids possess.7,134 In this review, we define cardioids as possessing four key characteristics: self-organization, complex 3D architecture, cellular diversity, and functional mimicry (Figure 6).


Figure 6. Schematic depicting four key features of cardiac organoids. Cardiac organoids exhibit: (1) self-organization, where stem cells autonomously aggregate and differentiate to form tissue structures; (2) cellular heterogeneity, with multiple cardiac cell types contributing to cardioid function; (3) complex 3D architecture, including heterogeneous layer formation, primitive vascularization, and chamber-like cavity formation; and (4) functional mimicry, as demonstrated by synchronous beating and responsiveness to external stimuli such as drug exposure. Created with BioRender.com.

3.1. Cardioid features

A defining hallmark of cardioids is their intrinsic ability to self-organize into 3D structures without the need for scaffolding or external patterning. Typically, cardioids are formed via directed differentiation of PSCs, allowing cardioids to develop diverse cellular populations through a process that closely mimics early embryonic development.12 This process enables cardioids to develop a 3D architecture that closely resembles the in vivo organization of embryonic cardiac tissue. This includes multiple organized layers of a diverse population of cells, including CMs, ECs, and CFs, as well as surrounding ECM components that help guide self-organization.135–143

In contrast, spheroids mainly refer to simple, scaffold- free aggregates of a single cell type, while assembloids describe the fusion of organoids with other tissues or additional organoids.7,144 Engineered heart tissues are another type of in vitro model that are sometimes referred to as cardioids. Although engineered heart tissues can exhibit multi-dimensional architectures, they are typically fabricated using forced assembly techniques involving pre-patterning, forced aggregation, molds, scaffolds, or biomaterial supports.7 Additionally, most engineered heart tissues utilize pre-differentiated cardiac cells, bypassing the self-organization of PSCs. However, because these cells are derived independently, the constructs lack the intrinsic signaling interactions between myocytes and non-myocytes that coordinate developmental cell fate decisions, leading to incomplete cellular differentiation and limited maturation. This approach necessitates separate differentiation protocols for each major cell type (e.g., Wnt/β signaling for CMs, VEGF/BMP for ECs, and FGF/TGF-βi for CFs).21,22,38,39,46,47 These models tend to exhibit more adult-like properties and, as a result, are often used for electromechanical models of the heart. Additionally, this method often fails to incorporate minor cardiac cell types due to the lack of well-defined differentiation protocols.20 Furthermore, many engineered heart tissues have simple designs—such as strips, rings, patches, tubes, and single chambers—that often recapitulate only one cardiac property rather than replicating the full architectural complexity and functionality of the developing heart.26–31,43–45,50,52,129

Unlike traditional in vitro cardiac models, cardioids recapitulate key morphogenetic events observed in early cardiac development including chamber formation, outflow tract emergence, and lineage specification.135–138 These processes are absent in traditional 2D monolayer cultures and only partially represented in other 3D models. Many cardioids exhibit electromechanical functions including spontaneous contractions and electrical conduction, demonstrating primitive but physiologically relevant early cardiac activity. Additionally, some cardioids display rudimentary aspects of valvular and conduction system development, reminiscent of embryonic stages of the heart. These features make cardioids valuable models for studying cardiac morphogenesis, congenital heart defects, and disease pathophysiology—topics that will be further explored in future sections.7,14,134

While traditional cardioids form through self-assembly, engineering strategies can be used to refine and support self-organization, enhancing reproducibility, and structural complexity while still preserving the intrinsic mechanisms that drive heart formation. These hybrid approaches blur the line between cardioids and engineered heart tissues, but if self-organization remains a defining feature post-printing they can still be classified as cardioids.

3.2. Cardioid formation

Early cardiac differentiation protocols relied on embryoid bodies-based differentiation, ESCs or iPSCs spontaneously aggregated in suspension cultures, forming 3D clusters.145 These aggregates developed multiple germ layers including the cardiac mesoderm without external signals, and within several days a small subset of cells would begin spontaneous contraction. While this approach was cost-effective, scalable, and required minimal intervention, it yielded highly heterogeneous populations with low CM efficiency, limiting its applicability for cardiac-specific models.145,146

To improve cardiac cell, yield, and uniformity, differentiation strategies shifted toward directed monolayer-based approaches, which became increasingly efficient at generating CMs.21,22 However, this came at the cost of replicating 3D cellular interactions and incorporating essential non-myocyte populations.20 Since heterogeneous cellular composition is critical for functional cardiac tissues, interest in 3D differentiation models has re-emerged, but with greater emphasis on directed differentiation strategies.16

Self-assembly-based cardioid formation typically begins with PSCs being cultured in suspension culture, where intrinsic signaling and cell–cell interactions promote cellular aggregation. Suspension culture environments—most commonly ultra-low attachment plates—provide a scaffold-free setting in which cells can self-organize.136–138,142,143 Although scaffolding is not as common, in cardioid development, some researchers chose to encapsulate their cardioid in a supporting ECM such as collagen or Matrigel®, to provide additional biological cues for differentiation, better mimicking the 3D aspect of the native cardiac microenvironment.135,142

Comparable to traditional monolayer approaches, the most common method for cardioid differentiation involves modulating the Wnt/β-catenin pathway with small molecules. Activation of the pathway—typically with Chir—triggers mesodermal induction, where PSCs first differentiate into mesodermal progenitors and subsequently into cardiomesodermal progenitors.83 Additionally, growth factors such as bone morphogenetic protein 4 (BMP4), activin A, Wnts, and FGFs are utilized to help generate cardiac mesodermal cells. From the cardiomesoderm, various progenitor cells spawn the major cardiac cells: CMs, cardiac ECs, and CFs.7,20 VEGF—a key player in vascular specification, FGF and TGF-βi—commonly used for the generation of epicardial cells, are common growth factors used in cardioid protocols.7,12

Cardioid research gained traction in 2021, with several overlapping studies demonstrating the emergence of cardiac structures through precise modulation of Wnt, BMP, and FGF signaling (Table 4). Hofbauer et al.138 achieved chamber-like structures with endocardial and epicardial layers and clarified the relationship between HAND1, a transcription factor linked to developmental heart chamber defects, and chamber formation. Lewis-Israeli et al.136 used three-step Wnt modulation (activation/inhibition/activation) to guide atrioventricular specification, generating cardioids with distinct atrial and ventricular CMs (Figure 7A). In 2023, Volmert et al.143 used fatty acid supplementation to induce a metabolic shift from glycolysis to fatty acid oxidation (Figure 7B). They observed the formation of distinct atrial and ventricular regions, endogenous anterior–posterior patterning following retinoic acid exposure, and the emergence of valvular and conductance cells for the first time within a cardioid.

Table 4. Highlights from cardioid publications in recent years

Culture method Cells/tissue Biomolecules & growth factors Features References
Ultralow-attachment 96-well plate, aggregates embedded in Matrigel® droplets hESCs and hiPSCs → CMs, endocardial-like cells, foregut endoderm, septum transversum-like mesenchyme Chir (7.5 µM, day 0), IWP2 (5 µM, day 3–5) Chamber-like structures, formation of primitive heart fields, endocardial lining developed, vascular-like endothelial organization, primitive heart field emergence, foregut endoderm regions 135
Ultralow-attachment 96-well plate hESCs & hiPSCs → CMs, endocardial-like cells, epicardial-like cells Chir, BMP4, activin A, FGF2, retinoic acid, LY294002, IWR-1 Chamber-like structures, epicardial and endocardial-like layers, fibrotic response upon cryoinjury 138
Ultralow-attachment 96-well plate hESCs & hiPSCs → atrial & ventricular CMs, epicardial cells, endocardial cells, ECs Chir, C-59, BMP4, activin A Distinct atrial and ventricular regions, myocardial cavities, pre-gestational diabetes model 136
Ultralow-attachment 96-well plate mESCs → CMs, early heart field progenitors, vascular-like ECs, endocardial-like cells Chir, bFGF, VEGF, ascorbic acid Formed gastruloids, early heart field-like structures, multi-lineage interactions; first heart field patterning, early vascular-like structures, cardiac crescent, and heart tube-like structure gut-like tube formation 137
Tissue culture plate (iPSCs → mesendoderm progenitors), 6-well low-attachment tissue culture plates ( mesendodermal spheroids) hiPSCs → CMs, mesodermal derivatives, gut-like endodermal cells, epicardial-like cells, smooth muscle cells Chir, IWP2 FGF, retinoic acid, ascorbic acid Atrial/nodal CMs development, cardiac (mesoderm), and gut (endoderm) tissue formation, epicardial layer and contractile smooth muscle cells (peristalsis behavior) development 139
AggreWell™ 800 hESCs & hiPSCs → CMs, epicardial-like cells, foregut- derived hepatic progenitors, and mesenchymal cells Chir, retinoic acid, BMP4, IWP-4 Co-culture of CM aggregates and PE/STM foregut organoid formed epicardium-myocardium organoids, epicardial-like layer surrounding myocardium layer, ECM deposition at the periphery 140
Six-well plates on orbital shaker hiPSCs → CMs, epicardial cells CFs, vascular endothelial cells, neural & mesodermal derivatives Chir, FGF2, VEGF, ascorbic acid, IGF, HGF Thin-walled, dilated chamber-like structures, elaborate neuron structural network, outflow tract-like structure 141
Ultralow-attachment 96-well plate, collagen embedment post-differentiation hiPSCs → ventricular CMs, pacemaker cardiomyocytes, epicardial cells, epicardium- derived cells BMP4, bFGF, retinoic acid, IWP2, VEGF Generated epicardioids, vessel-like structures, ventricular myocardium and epicardium layers 142
96-well ultra-low-attachment plates hESCs & hiPSCs → ventricular and atrial CMs, valve cells, proepicardial-derived cells, epicardial cells, stromal cells, cardiac progenitor cells, conductance cells, ECs Chir, BMP4, activin A, maturation media (oleic acid, linoleic acid, palmitic acid, L-carnitine), Wnt-C59 Large atrial & ventricular chambers, retinoic acid gradient-driven anterior–posterior patterning, post-natal metabolic activity 143

Notes: LY294002 is a protein inhibitor; IWP2, IWP-4, IWR-1, and Wnt-C59 are Wnt signaling pathway inhibitors.

Abbreviations: bFGF or FGF2: Basic fibroblast growth factor; BMP4: Bone morphogenetic protein 4; CFs: Cardiac fibroblasts; Chir: CHIR99021- glycogen synthase kinase 3 beta inhibitor; CMs: Cardiomyocytes; ECs: Endothelial cells; ECM: Extracellular matrix; FGF: Fibroblast growth factor; hESCs: Human embryonic stem cells; HGF: Hepatocyte growth factor; hiPSCs: Human induced pluripotent stem cells; hPSC: Human pluripotent stem cells; HUVECs: Human umbilical vein endothelial cells; IGF: Insulin-like growth factor; iPSC-CMs: Induced pluripotent stem cell-derived cardiomyocytes; iPSC-ECs: Induced pluripotent stem cell-derived endothelial cells; PE/STM: Pro-epicardium/septum transversum; TGF-β: Transforming growth factor beta; VEGF: Vascular endothelial growth factor.


Figure 7. Examples of different approaches to cardioid formation. (A) Lewis-Israeli et al.136 utilized a three-step WNT modulation protocol (left) to generate cardioids with distinct atrial and ventricular regions. A microscopic image of a day 15 cardioid (right) displays expression of DAPI (blue), mature ventricular MYL2 (green), and atrial MYL7 (red). Scale bar = 500 μm. (B) Volmert et al.’s schematic143 (left) illustrates their differentiation protocol and fatty acid supplementation strategy. Immunofluorescence imaging of a day 30 cardioid (right) cultured in the advanced maturation media (EMM2/1) demonstrates distinct atrial and ventricular regions, as evidenced by expression of atrial marker NR2F2 (green), ventricular marker MYL3 (red), and DAPI (blue). Scale bar = 200 μm. (C) Branco et al.’s schematic140 (left) shows a co-culture strategy with foregut-derived organoids, and the microscopic image (right) displays a day 15 epicardium-myocardium cardioid stained for mature ventricle marker MLC2V (green), atrial/immature ventricle marker MLC2A (red), and DAPI (blue). Scale bar = 100 μm. Panels A, B, and C were adapted from refs. 136, 143, and 140, respectively, under Creative Commons Attribution 4.0 International (CC BY 4.0).

Proper cardiac morphogenesis depends on mechanical cues and paracrine signaling from neighboring tissues, such as the endothelium and foregut. Several studies have attempted to incorporate the generation of multiple germ layers to better mimic early heart development. Rossi et al.137 developed gastruloids, which mimic gastrulation—the embryonic stage where the three germ layers form. These pre-cardiac models expressed both first and second heart field progenitors and contained a primitive gut-like tube, vascular network, and endocardial-like layer. Building on this concept, Drakhlis et al.135 generated heart-forming organoids that included early heart and foregut tissues, comprising mesodermal layers lined with endocardial-like cells and splanchnic mesoderm, along with gut endodermal regions. Silva et al.139 further demonstrated that gut–heart interactions enhanced mesodermal signaling, promoted advanced structural and functional maturation of CMs, induced atrial/nodal subtype specification, and observed the development of contractile smooth muscle-like cells that exhibited peristalsis-like movements. Collectively, these studies illustrate that multi-germ layer interactions enhance CM maturation and promote the development of specialized cardiac subtypes, thereby improving the physiological relevance of cardiac organoids for studying complex processes beyond early development.

Beyond modeling early cardiac development, some studies have explored multi-organ interactions to better understand cardiogenesis in a broader embryonic developmental context. Olmsted and Paluh141 created elongating multi-lineage organized cardiac gastruloids, which exhibited chamber-like structures, outflow tractlike patterning, as well as an elaborate neural network, offering insight into cardio-neuro interactions during cardiogenesis and neurogenesis.

Complex cardioid systems have been achieved through co-culture approaches. Branco et al.140 developed pro- epicardium/septum transversum foregut organoids which contained both epicardial progenitors and hepatic foregut derivatives, reflecting the developmental link between the heart and liver. When combined with CM aggregates, epicardium-myocardium organoids formed, in which an epicardial-like layer surrounded the myocardium, influencing cardiac maturation and leading to ECM deposition (Figure 7C).140

3.3. Applications

Cardioid’s ability to mimic key morphogenetic processes, including chamber formation, metabolic transitions, and electrophysiological activity, make them well-suited for investigating both normal and pathological cardiac function. Furthermore, cardioids’ 3D architecture, cell diversity, and functional properties enable a more comprehensive assessment of drug-induced effects, ranging from electrophysiological disturbances to tissuespecific toxicity and regenerative potential.

Cardioids have provided key insights into developmental defects, injury responses, and cardiac regeneration. Hofbauer et al.138 observed physiologically relevant responses, including severe necrosis, continued contractions, fibroblast migration toward the injury site, and ECM accumulation, after subjecting their cardioids to cryoinjuries, mirroring aspects of both normal wound healing and pathological fibrosis. Voges et al.147 also used cryoinjury to assess the regenerative capacity of early- stage human heart tissue, demonstrating high rates of CM proliferation and recovery of cardioid contractility, suggesting an innate regenerative potential in immature cardiac tissue. Lewis-Israeli et al.136 investigated the effects of pregestational diabetes on cardiac development by exposing heart-forming organoids to hyperglycemic conditions, resulting in hypertrophic phenotypes, reduced mitochondrial content, dysfunctional lipid metabolism, and structural disorganization.

Cardioids have also proven particularly effective in identifying off-target effects of non-cardiac drugs. Ondansetron (Zofran®), an anti-nausea medication commonly prescribed during pregnancy, has been linked to congenital heart defects.148 When cardioids were exposed to Zofran® at increasing concentrations (1, 10, and, 100 μM), ventricular CM populations were significantly reduced in a dose-dependent manner, while atrial CMs remained largely unaffected. At the highest concentration, cardioids exhibited structural disorganization and loss of chamber wall definition.143 Similarly, cardioids have been used to investigate the cardiotoxic effects of doxorubicin, a widely used anticancer drug. Post-myocardial infarction organoids exposed to doxorubicin (0.1–50.0 µM) exhibited decreased contractile function, increased cell death, and severe structural disruptions in CMs, in a dose-dependent manner, with infarcted cardioids showing side effects at lower dosages than non-infarcted control organoids, consistent with the clinical observations of doxorubicin- induced cardiomyopathy in patients with pre-existing cardiovascular conditions.149,150 In the same study, cardioids were used to investigate JQ1, a potential heart-failure drug candidate. Infarcted organoids treated with JQ1 exhibited reduced fibrosis and improved synchronized beating, suggesting its potential as a therapeutic for post-MI recovery.149

These studies highlight the value of cardioids as physiologically relevant models for disease modeling, regenerative medicine, drug safety testing, and therapeutic screening. Their small size—typically ranging from 1 to 2 mm—enables high-throughput screening, optical accessibility, and efficient nutrient diffusion, making them well-suited for developmental and pharmacological studies. However, this microscale also imposes limits on vascularization, maturation, and scalability, which restrict their use in modeling adult physiology/pathology or serving as implantable grafts. As cardioid platforms continue to evolve, integrating them with bioengineering technologies such as bioprinting may help overcome these limitations and expand their applicability to more translational contexts.

3.4. Limitations

While cardioids have advanced our ability to model human cardiac development and disease, several challenges hinder their clinical and translational potential. These include limited tissue maturity, diffusion constraints due to the absence of vasculature, batch variability, and scalability issues.8 Overcoming these challenges will be essential for advancing cardioids in disease modeling, drug discovery, and regenerative medicine.

As with all engineered cardiac tissues, achieving maturity remains one of the most pressing challenges.8 PSC-derived CMs often resemble fetal cells rather than adult CMs, exhibiting small, round morphology, unorganized sarcomeres, few mitochondria, glycolysis-dependent metabolism, asynchronous contractility, and immature calcium-handling properties.124 In contrast, mature CMs exhibit elongated morphology, aligned and organized sarcomeres, abundant mitochondria, oxidative metabolism, synchronized contractions, and efficient calcium handling—features essential for adult-like cardiac tissue function. This immaturity within cardioids not only restricts their clinical applicability but also limits their ability to model adult-onset diseases or assess drug responses in fully developed tissues. Previous studies with bioprinted constructs have demonstrated that strategies such as bioreactors, physical conditioning, and co-culture techniques are necessary to enhance tissue maturation. Thus, these strategies are expected to be critical for improving cardioid maturation. Physical conditioning of increasing intensity was demonstrated to be effective at encouraging an adult-like maturation state of early iPSC-derived CMs if initiated soon after spontaneous contractions began.129 Given the developmental nature of cardioids, implementing these strategies may be particularly impactful for enhancing maturity. The development of a fully perfusable vasculature is crucial for advancing current cardioid toward more physiologically relevant models. Current cardioid models exhibit disorganized capillary structures and lack defined arteries, arterioles, veins, and venules. As a result, they rely on passive diffusion for oxygen and nutrient transport, restricting their size to a microscale range.135,136,143,151 Additionally, the lack of functional vasculature increases the risk of necrotic core formation in larger constructs. Thus, vascularization strategies must be optimized so that cardioids can be successfully scaled up. This presents a unique challenge, as the heart has the highest oxygen demand of any organ, requiring a dense vascular network that is difficult to replicate in vitro.33

The self-organizing nature of cardioids results in batch-to-batch variability, which poses a challenge for consistent structural and function outcomes. Small variations in culture conditions can lead to significant differences between and within batches, posing challenges for standardization, regulatory approval, and clinical translation. Additionally, current methods for generating cardioids are not high-throughput, limiting their use in large-scale pharmaceutical screening. Emerging fabrication strategies, including bioprinting, offer promising solutions to address these challenges by improving scalability, reproducibility, and vascularization.

4. Progress toward cardioid bioprinting

Organoid bioprinting is an emerging technology that has successfully yielded functional bioprinted organoids for many organ systems including the brain, kidney, intestine, liver, lungs, and pancreas151–156. Yet, progress in cardioid bioprinting lags behind other organs due to the mechanical complexity required to support continual contraction, unidirectional force transmission, and synchronized electrical activity, as well as the heart’s high metabolic demand for oxygen and nutrients. 157,158 In this review, we consider two approaches to cardioid bioprinting: (i) using bioprinting strategies to print individual organoids and (ii) using cardioids as the building blocks to print cardiac constructs. In this section, we will discuss the progress in cardioid bioprinting toward addressing the challenges of cardiac tissue engineering discussed in section 2.2, as well as how bioprinting addresses the limitations of standard cardioids.

One major challenge in cardiac tissue engineering is achieving heterogeneous physiological cellular density. Cardioids naturally achieve these densities across multiple cardiac cell types; however, their average diameter is typically only 1–2 mm.135,136,143,151 Bioprinting, as we have seen, can easily produce macroscale cardiac constructs capable of maintaining structural fidelity. Furthermore, there has been recent progress in supporting the printing of PSCs, which are the predominant cells used to generate organoids, though their application is still rather limited.159 Kupfer et al.23 used this approach to develop human chambered muscle pumps (HCHAMPs)—3D EBB-printed chambered cardiac constructs. To support both iPSC encapsulation and CM differentiation, they optimized a GelMA/collagen methacrylate bioink supplemented with native cardiac ECM proteins. The HCHAMPs featured a macroscale (1 cm long), two-chambered structure with inlet and outlet vessels—enabling perfusion, pressure/ volume dynamics, continuous action potentials, and responsiveness to pacing and drug stimuli. However, the HCHAMPs lacked cellular heterogeneity, only containing CMs, which limited their ability to replicate CMs and non-myocyte interactions and develop vasculature.23 Expanding on the novelty of this approach by utilizing cardioid differentiation protocols, instead of CM-only protocols, could simultaneously address many cardiac engineering challenges, including the lack of macro-scale cardioids, the lack of cellular diversity of printed constructs, and limited functional complexity of both cardioids and printed cardiac constructs. However, larger constructs with higher densities exacerbate the need for vascularization.

Another challenge is integrating vascular and anisotropic organization without disrupting the self-organization behavior critical to cardioid development. Direct printing, indirect formation through sacrificial techniques, and encouragement of de novo formation of vasculature have all been used to create vessels and vascular networks in printed constructs, but standard cardioids rely solely on self-organization of vessel-forming cells such as ECs and VSMCs. Furthermore, cardioids rely on self-organization to form the anisotropic organization of cardiac cells and ECM necessary to carry out cardiac-specific tasks such as electrical signal propagation, contraction, and efficient ejection throughout chambers, while this organization must be manually achieved in printed constructs. Hybrid approaches have been developed to combine the manual organization of cells and ECM without overriding self-organization but instead enhancing it. Bioprinting-assisted tissue emergence (BATE) developed by Brassard et al.151 is a novel organoid bioprinting technique that involves the usage of a syringe-based extrusion printer coupled to a microscope and a manually controlled stage to manipulate cell spatial position within ECM, allowing for the printing of centimeter-scale human intestinal, connective, and vascular tissues with complex branched vasculature and luminal structures. If combined with directed differentiation, BATE and similar approaches could provide finer spatial control over cardiac tissue organization, potentially enabling the recreation of cardiac structures such as valves, coronary arteries, and defined atrial and ventricular chambers while allowing the self-organization of the appropriate cells toward the pre-formed structures. Furthermore, combining BATE with the second bioprinting approach of using pre-formed cardioids could further enhance self-organization.

Ahrens et al.160 embedded anisotropic organ building blocks (aOBBs) within a gelatin-fibrinogen bioink to print cardiac macrofilaments and tissue sheets. Within the cardiac sheets, the aOBBs aligned according to the printing patterns, which included linear, spiral, chevron, and circular arrangements. Comparison of tissues printed in a parallel alignment had more than double the contractile force of tissues printed with a perpendicular aOBB alignment. In the macrofilaments, aligned tissues exhibited higher contractile forces, sustained higher frequencies during electrical pacing, and demonstrated more synchronous action potentials compared to spheroid controls.160 While the aoBBs were not true cardioids, we can infer that similar usage of encapsulated cardioids printed using BATE would produce similar, if not better, functional outcomes. Similarly, Skylar-Scott et al.101 employed the SWIFT technique to print sacrificial channels into cardiac organ building blocks (OBBs) matrices containing iPSC-CMs and primary CFs. This approach produced high-density tissues (~240 million cells/mL) containing perfusable vascular channels, demonstrating how printed organoid matrices could be used to produce vascularized cardiac tissues.

For fabricating macroscale constructs, EBB has dominated the field, while LBB is preferred for high-resolution microarchitectures. Droplet-based bioprinting (DBB), however, struggles with large-tissue fabrication, making it less suited for cardioid bioprinting in its current state.161 Yet, advancements in biofabrication techniques and multi-modal printing strategies may soon enable high-fidelity, scalable printing of cardioids, expanding their clinical application. Volumetric bioprinting has recently emerged as a high-speed, high-resolution light-based modality that enables the creation of entire tissue constructs by projecting a series of optical patterns from multiple angles.162 While it has not been utilized with cardioids, volumetric bioprinting has already demonstrated geometrically complex, centimeter-scale liver and bone tissue using organoid-laden bioinks.163 Volumetric bioprinting and other hybrid approaches integrate developmental self-organization with engineering control, improving reproducibility, vascularization, and tissue scaling.

Whether printing cardioids or printing with cardioids, bioprinting enhances reproducibility and scalability, enabling automated, high-throughput production of cardiac tissues with uniform structure and composition.153 Commercially available bioinks have already demonstrated the ability to support functional cardiac tissue engineering in several studies. For example, Kupfer et al. 23 combined commercially sourced ColMA (Advanced BioMatrix) with GelMA to bioprint constructs exhibiting measurable contractile force, synchronous electrical activity, and perfusability. Wolfe et al.25 developed a patient-derived bioprinted patch for congenital heart disease modeling using GelMA Laminink-521, a commercially available bioink sold by CELLINK. Additionally, Jia et al.91 directly bioprinted perfusable vascular constructs using a blend bioink consisting of laboratory-prepared GelMA and PEGDA purchased from JenKem®. These examples are representative of the broader body of work demonstrating that commercially available bioinks can support functional cardiac tissue engineering. Additionally, these commercial bioinks can offer extensive quality control that may be difficult to achieve in a research environment. Although bioprinted cardioids are still in their infancy, improving scalability and reproducibility will be essential as organoids transition from research tools to clinical and commercial platforms.

5. Conclusion

Replicating the cellular, functional, and structural complexity of the native heart has been a longstanding challenge in cardiac tissue engineering. In this review, we examine how two concurrently evolving technologies—3D bioprinting and cardioid technology—independently address these challenges. Bioprinting offers scalability, spatial precision, and structural control, while cardioids provide multi-cellular diversity, developmental relevance, and physiological functionality.

While each approach has advanced the field, both face limitations that have restricted clinical and commercial translation, yet may be resolved through their convergence. Guiding or reinforcing cardioid self-organization through engineered spatial cues or using pre-formed cardioids as modular units within bioinks could generate more mature, vascularized, and functionally relevant cardiac tissues. Although cardiac bioprinting remains in its early stages, with challenges such as cellular immaturity, improper vascularization, and lack of scaling needing to be addressed, emerging proof-of-concept studies provide a strong foundation for future progress.

As both biofabrication techniques and cardiac stem cell differentiation protocols continue to advance, the integration of engineering and developmental biology will drive the next generation of in vitro cardiac models—supporting applications in developmental and disease modeling, drug screening, and ultimately cardiac repair and replacement.
