RESEARCH ARTICLE

Fabrication of bacteriorhodopsin-embedded hydrogel construct for biocompatible photosensitive device

Mian Wu1,2,3 ,  Feng Lin1,2,3 ,  Yu Song1,2,3*
Show Less
1 Department of Mechanical Engineering, Tsinghua University, Beijing, China
2 Biomanufacturing and Rapid Forming Technology Key Laboratory of Beijing, Beijing, China
3 Key Laboratory of Advanced Materials Processing Technology of Ministry of Education, Beijing, China
IJB, 4454 https://doi.org/10.36922/ijb.4454
Submitted: 6 August 2024 | Accepted: 24 September 2024 | Published: 25 September 2024
© 2024 by the Author(s). This article is an open access article distributed under the terms and conditions of the Creative Commons Attribution 4.0 International License ( https://creativecommons.org/licenses/by/4.0/ )
Download PDF
Cite
XML
Abstract

Bacteriorhodopsin (br) is a promising photosensitive material with applications in energy conversion, biosensors, and optoelectronic devices due to its bio-sourced origin and photoelectrical properties. Despite advancements in recent years, the integration of br-based devices necessitates the use of materials with little biocompatibility and fabrication techniques with restricted customizability, limiting potential applications such as optocontrol of cell behavior, implants with 3D patterning for retinal disease treatment, and light-sensitive cell robots. To solve this limitation, this study presents a novel approach by embedding br into a hydrogel matrix. It utilizes an extrusion-based and 3D bioprinting technique, showcasing its light-sensitive characteristics within a fully biocompatible construct. The hydrogel, comprising gelatin and sodium alginate, offers excellent printability for generating structured designs with versatile patterns. Photoelectrical properties of the fabricated br-embedded hydrogel construct, such as differential response, light intensity sensitivity, and br concentration sensitivity, are identified through electrochemical characterization. The temporal and spatial pattern recognition ability, based on the photoelectrical characteristics, is demonstrated through modulated light illumination and different patterns of printed hydrogel construct. Pattern recognition ability was then applied to reconstruct images containing different Latin letters. This research presents a novel method for the fabrication of patterned hydrogel constructs with high biocompatibility and distinctive light-responsive properties, expanding the potential applications of br in bio-related scenarios.
